- Classic OEM design
- Optimized optical design with OSRAM vehicle LEDs
- Higher energy efficiency
- Zero noise, zero radio interference, CISPR 25 Class 3
- PC lens surface hardened
- Bracket mount optional (bottom right)
| Model: | E-HDL-7-RD-RL | |
| Functions, Homologation | ||
| Functions: | Low Beam, High Beam, Parking | |
| Homologations: | ECE R112, R7, R10 DOT FMVSS 108 | |
| Optical & Electric Features | ||
| LED Type: | Low Beam:2pcs 15W 3chip LEDs High Beam:2pcs 12W 2chip LEDs Position: 80pcs 0.2W LEDs | |
| Emitting Color: | White | |
| Color Temp: | White:5700K-6500k | |
| Raw lumen | Low beam: 2800LM High beam: 4500LM Position: 777.6LM | |
| Effective lumen | Low beam: 909LM High beam: 1110LM Position: 116LM | |
| Energy Consumption: | Low beam: 29W; High beam: 26W; Position: 1W; | |
| Current Draw @ 12V: | Low beam: 2.41A High beam: 2.16A (Low beam on at high beam) Position: 0.08A | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 3 | |
| Operating Voltage: | 10~30VDC | |
| Connector: | H4 | |
| Mechanical Features | ||
| Size: | Approx. Ø176 X 101mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Lens Processing: | Surface Hardened | |
| Bracket Material: | Stainless Steel | |
| IP Rate: | IP66, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
