High end LEDs from LUMILEDs or CREE optional OSRAMOr
High efficacy, high lumen output.
Stylish & fashionable dark appearance.
Tough design for heavy duty vehicles, heavy duty trucks,construction machines, mining vehicles, etc.
Zero radio interference, Zero noise.
Anti-corrosion housing, protectionagainst up to 480Hrs salt spray.
Vibration: 15.3Grms Shock:60G frequency:20-2000Hz
| Model: | E2165F | |
| Functions, Homologation | ||
| Functions: | Work Light(Flood Beam)/ Reversing Light | |
| Homologations | ECE R10, R148(Optional) | |
| Optical & Electric Features | ||
| LED Type: | OEM Vehicle LED(s) | |
| Color Temp: | 5300-6000K(White) | |
| Raw Lumen: | 9450LM | |
| Effective Lumen: | 5500LM | |
| Raw Power: | 90W | |
| Effective Power: | 62W(ATM) | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 5 | |
| Operating Voltage: | 10V~30V | |
| Connector: | DT / AMP/ Cable (Optional) | |
| Mechanical Features | ||
| Size: | 100X70X113MM | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Mount(optional): | Bottom Bracket | |
| Bracket Material: | Stainless Steel | |
| IP Rate: | IP67, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
