| Model: | E7101 | |
| Functions, Homologation | ||
| Functions: | Low Beam, High Beam, Turn,Side DI, Parking | |
| Homologations: | DOT FMVSS 108/SAE J914/ SAE J588/ SAE J222 | |
| Optical & Electric Features | ||
| LED Type: | Ordinary LED / OSRAM LED (optional) | |
| Emitting Color: | White Amber (Turn) | |
| Color Temp: | White:5700K-6500k Amber:1600-1800K (Turn) | |
| Energy Consumption: | Low Beam 24W; High Beam 24W; Turn Light 2W; Parking 0.4 | |
| Current Draw @ 12V: | Low Beam 1.91A; High Beam 1.91A; Turn Light 0.17A; Parking 0.03A | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 3 | |
| Operating Voltage: | 10~30VDC | |
| Connector: | 6 pin DT /AMP /Cable (optional) | |
| Mechanical Features | ||
| Size: | 232X 164 X 158mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Lens Processing: | Surface Hardened | |
| PC Brand: | COVESTRO 2407 | |
| Bracket Material: | Stainless Steel | |
| IP Rate: | IP66, IP6K9K | |
| Work Temp: | ——40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
