| Model: | E-FL-5D-3 | |
| Functions, Homologation | ||
| Functions: | Fog Beam (Auxiliary) | |
| Homologations: | SAE J583-2005, R10 | |
| Optical & Electric Features | ||
| LED Type: | 5 pcs 5w LEDs | |
| Emitting Color: | Yellow | |
| Color Temp: | 2950~3350K | |
| Raw Lumen: | 1350LM | |
| Effective Lumen: | 762.3LM | |
| Illumination Distance: | 1 lux @54m | |
| Luminous Efficacy: | 39.09LM/W | |
| Raw Power: | 25W | |
| Effective Power: | 19.5W | |
| Current flow: | 1.625A@12V, 0.8125@24V | |
| Electromagnetic Features | ||
| EMC Grade: | ECE R10 | |
| Operating Voltage: | 10~30VDC | |
| Connector: | Open Cable | |
| Mechanical Features | ||
| Size: | 83.2x89.75x77.5mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| PC Brand: | COVESTRO 2407 | |
| Bracket Material: | Stainless Steel | |
| IP Rate: | IP66, IP6K9K | |
| Work Temp: | —40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
