Designed with latest optic lens of even flood light distribution, here comes new work lamp
with performance far better than its rivals, in terms of compact size, high power,
natural white light output, high level vibration resistance, etc.
Bezel less
Typical 3.9" body could withstand vibration of up to 15.3Grms
equipped with patented vibration-resistant and high strength spring bracket.
Enabling drivers to work safely and comfortably against various harsh conditions.
No longer a problem for numerous small vehicleswhere the fixture space was too small and light was not enough.
EMC level up to CISPR 25 Class 4
ATM(Active Thermo Management).
| Model: | E2192LM | |
| Functions, Homologation | ||
| Functions: | Flood Beam | |
| Homologations | ECE R10 | |
| Optical & Electric Features | ||
| LED Type: | OEM Vehicle LED(s) | |
| Color Temp: | 5000-5500K | |
| Raw Lumen: | 6950LM | |
| Effective Lumen: | 4880LM | |
| Raw Power: | 63W | |
| Effective Power: | 60W(ATM) | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 4 | |
| Operating Voltage: | 10V~30V | |
| Connector: | DT / AMP/ Cable (Optional) | |
| Mechanical Features | ||
| Size: | 100X70X131MM | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Mount(optional): | Bottom Bracket | |
| Bracket Material: | Stainless Steel | |
| IP Rate: | IP67, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
