ECER149 /DoT homologated for onroad purpose.
Flexible and generic design out of compact body.
Multiple mounting positions available.
Multiple mounting brackets optional.
Stylish dark appearance design.
| Model: | E1369 | |
| Beam Pattern: | Low Beam, High Beam,Position | |
| Homologation: | R10 | |
| LED Type: | OEVehicle LEDs | |
| Color Temp: | 5700K | |
| Raw Lumen: | Low Beam: 4000LM High Beam: 5000LM | |
| Effective Lumen: | Low Beam: 2100LM High Beam: 1650LM | |
| Raw Power: | Low Beam: 40W High Beam: 40W position：5W | |
| Effective Power: | Low Beam: 30W High Beam: 30W position：3W | |
| 1 LUX @ m | Low Beam:70M High Beam: 221M | |
| EMC Grade: | CISPR 25 Class 3 | |
| Operating Voltage: | 10~30VDC | |
| Connector: | Open Cable | |
| Mechanical Features | ||
| Size: | 88X 88X 61MM | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Lens Processing: | Surface Hardened | |
| PC Brand: | COVESTRO 2407 | |
| IP Rate: | IP66, IP6K9K | |
| Work Temp: | -40-+50°C | |
| Life Time: | >30,000H | |
| Warranty: | 3 Years | |
