| Model: | E2136B | |
| Functions, Homologation | ||
| Beam pattern | Asymmetric Lens pattern | |
| Homologations | ECE R23, R10 | |
| Optical & Electric Features | ||
| LED Type: | 18pcs 1W LED(s) | |
| Color Temp: | 5000~6500K | |
| Raw Lumen: | 2340LM | |
| Effective Lumen: | 1318LM | |
| Luminous Efficacy: | 87.8LM/W | |
| Raw power | 18W | |
| Effective Power: | 15W | |
| Current Draw: | 1.25A@12V; 0.625A@24V | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 5 | |
| Operating Voltage: | 10V~30V | |
| Connector: | DT / AMP/ Cable (Optional) | |
| Mechanical Features | ||
| Size: | 98.5 X 98.5 X 59 mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| PC Brand | COVESTRO 2407 | |
| Bracket: | Stainless Steel | |
| IP Rate: | IP67, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
